DOUBLE HUNG
Series 100
Tubular Sections
Triple Weather Stripping
Historic Details
The Skyline Series 100 Double Hung windows are an extraordinary family of windows that can be manufactured in a variety of shapes and sizes. The Series 100 windows adhere to modern performance standards while preserving classic architectural features from the past. Skyline’s in-house engineering team designs every feature of the Series 100 to replicate a multitude of existing window designs ranging from historical to modern by utilizing custom colors, historical metal trim, hand applied muntin grids and more. Harnessing modern technology such as Low-E coated insulated glass packages, a 4-1/2” deep window frame, triple weather stripping and ultra-lift balances, Skyline is capable of meeting or exceeding any modern day building requirements.
-
Architectural / Commercial / Historical
Custodial operated tilt in sash for easy cleaning
Glazing: 1 ¼” insulating glass
Triple muntin capability, full simulated divided lites
Triple weather-stripping for improved thermal and acoustical performance
4 ½" frame depth
Thermal bar insulated frames and sash members
High-performance balances for ease of operation
-
-
standard stock finishes - aama 2603
white interior / white exterior
white interior / bronze exterior
white interior / black exterior
black interior / black exterior
bronze interior / bronze exterioR
Custom Colors & Finishes Available
Upon Request
AAMA 2603
AAMA 2604
AAMA 2605
Hardware
standard sweep lock
optional LIFT handle
Testing
These values are dependent on the specifics of your project and may vary.
AAMA Rating
H-AW-50
Air @ 6.24 PSf (CFM/FT2)
0.29
Window test size
60" X 100"
Water
12 PSF
Window depth
4.5"
Glass thickness
1.25"
Structural load
75 PSF
Downloads
Skyline’s products are custom-made to meet specifications per project.
We have a large catalogue of drawings. Contact us for site specific details.
Series 100 Double Hung Operational Video
